STAINLESS STEEL MANDREL BENDS
16 gauge 304 stainless steel mandrel bends in 45, 90, 180 degrees.
Center line radius of either 1-1/2 multiplied by the tube size, or 2 multiplied by the tube size.
409 stainless steel bends are available but not in stock.
Other bend angles and leg lengths are available but not in stock.

1.5 x Diameter Center Line Radius                         2 x Diameter Center Line Radius
ID/OD
Part #		 OD/OD
Part #		 Bend
Angle		 A+B
Length		 CLR
(Radius)		 Tubing
Size

ID/OD
Part #		 OD/OD
Part #		 Bend
Angle		 A+B
Length		 CLR
(Radius)		 Tubing
Size
9671506 9871506 45 4.5" 2.25" 1-1/2"
9771507 9971507 45 5.5" 3" 1-1/2"
9671706 9871706 45 4.5" 2.625" 1-3/4"
9771707 9971707 45 5.5" 3.5" 1-3/4"
9672006 9872006 45 4.5"
 3" 2"
9772007 9972007 45 8" 4" 2"
9672206 9872206 45 5.5" 3.375" 2-1/4"
9772208 9972208 45 5.5" 4.5" 2-1/4"
9672507 9872507 45 6" 3.75" 2-1/2"
9772508 9972508 45 7.5" 5" 2-1/2"
9673010 9873010 45 6" 4.5" 3"
9773010 9973010 45 6.5" 6" 3"













ID/OD
Part # 		OD/OD
Part # 		Bend
Angle 		A+B
Length 		CLR
(Radius) 		Tubing
Size

ID/OD
Part #		 OD/OD
Part #		 Bend
Angle		 A+B
Length 		CLR
(Radius)		 Tubing
Size
9681507 9881507 90 3" 2.25" 1-1/2"
9781510 9981510 90 3" 3" 1-1/2"
9681707 9881707 90 3" 2.625" 1-3/4"
9781710 9981710 90 3.5" 3.5" 1-3/4"
9682007 9882007 90 3.5" 3" 2"
9782010 9982010 90 5" 4" 2"
9682209 9882209 90 4.5" 3.375" 2-1/4"
9782210 9982210 90 4.5" 4.5" 2-1/4"
9682509 9882509 90 4.5" 3.75" 2-1/2"
9782512 9982512 90 5.5" 5" 2-1/2"
9683012 9883012 90 6" 4.5" 3"
9783014 9983014 90 6.5" 6" 3"















OD/OD
Part #		 Bend
Angle		 A+B
Length		 CLR
(Radius)		 Tubing
Size



OD/OD
Part #		 Bend
Angle		 A+B
Length		 CLR
(Radius)		 Tubing
Size

9891546 180 3" 2.25" 1-1/2"

9991510 180 6.5" 3" 1-1/2"

9891747 180 3.25" 2.625" 1-3/4"

9991710 180 6" 3.5" 1-3/4"

9892008 180 4.5" 3" 2"

9992011 180 5.5" 4" 2"

9892024 180 4.5" 3" 2"

9992212 180 5.5" 4.5" 2-1/4"

9892208 180 8" 3.375" 2-1/4"

9992512 180 6" 5" 2-1/2"

9892224 180 17" 3.375" 2-1/4"

9993018 180 10" 6" 3"

9892510 180 6" 3.75" 2-1/2"







9892524 180 17" 3.75" 2-1/2"












ALUMINIZED STEEL BENDS

16 gauge Aluminized steel mandrel bends in 45, 90, 180 degrees.
Center line radius of either 1-1/2 multiplied by the tube size, or 2 multiplied by the tube size.
Other bend angles and leg lengths are available but not in stock.
We stock 3", 3-1/2", 4", 5" bends in 1.5D center line radius in bend angles of 15, 30, 45, 60, 75, 90 and 180.

Wide Radius Bends                                                                    Tight radius bends
ID/OD
Part # 		OD/OD
Part #		 Bend
Angle 		A+B
Length 		CLR
(Radius) 		Tubing
Size

ID/OD
Part # 		OD/OD
Part #		 Bend
Angle 		A+B
Length 		CLR
(Radius) 		Tubing
Size
EL45125 L45125 45 5" 2.5” 1-1/4"
9641206
 9841206
 45
 5.5"
 2"
 1-1/4"
9741510
45 8" 3" 1-1/2"
9641506 9841506 45 4.5" 2.25" 1-1/2"

9941507 45 5.5" 3" 1-1/2"
9641606 9841606 45 4.5" 2.4375" 1-5/8"
9741710
45 8" 3.5" 1-3/4"
9641706 9841706 45 4.5" 2.625" 1-3/4"

9941707 45 5" 3.5" 1-3/4"
9641806 9841806 45 6" 3" 1-7/8"
9742010
45 7.5" 4" 2"
9642006 9842006 45 3.5" 3" 2"

9942007 45 5.5" 4" 2"
9642106 9842106
 45 6" 3" 2-1/8"
9742210
45 7.25" 4.5" 2-1/4"
9642207 9842207 45 5.5" 3.375" 2-1/4"

9942208 45
 5.5" 4.5" 2-1/4"
9642507 9842507 45 6" 3.75" 2-1/2"
9742510
45 7.5" 5" 2-1/2"
9642710 9842710 45 8" 4.125" 2-3/4"

9942508 45 4" 5" 2-1/2"
9643010 9843010 45 8" 4.5" 3"
9743010 9943010 45 6.5" 6" 3"
EL45350 L45350 45 8" 5.25" 3-1/2"


EL45400 L45400 45 8" 6" 4"

EL45500 L45500 45 9" 7.5" 5"





















ID/OD
Part #		 OD/OD
Part #		 Bend
Angle		 A+B
Length		 CLR
(Radius)		 Tubing
Size

ID/OD
Part #		 OD/OD
Part #		 Bend
Angle		 A+B
Length		 CLR
(Radius)		 Tubing
Size
EL90125 L90125 90 4"
 2.5” 1-1/4"
9651205 9851205 90 5"
 2" 1-1/4"
9751510
90 6.5" 3" 1-1/2"
9651507 9851507 90 4" 2.25" 1-1/2"

9951507 90 3.25" 3" 1-1/2"
9651607 9851607 90 4"   2.4375" 1-5/8"
9751710
90 5.5" 3.5" 1-3/4"
9651707 9851707 90 3" 2.625" 1-3/4"

9951708 90 3.25" 3.5" 1-3/4"
9651807 9851807 90 3.25" 3" 1-7/8"
9752010
90 5" 4" 2"
9652007 9852007 90 4" 3" 2"

9952008 90 4.5" 4" 2"
9652107 9852107 90 5.25" 3" 2-1/8"
9752210 9952210 90 3.5" 4.5" 2-1/4"
9652209 9852209 90 5" 3.375" 2-1/4"
9752512
90 6" 5" 2-1/2"
9652509 9852509 90 4.75" 3.75" 2-1/2"

9952510 90 4" 5" 2-1/2"
9652712 9852712 90 6.5" 4.125" 2-3/4"
9753014
90 5" 6" 3"
9653012 9853012 90 6" 4.5" 3"

9953012 90 5" 6" 3"
EL90350 L90350 90 6" 5.25" 3-1/2"

EL90400 L90400 90 7.5" 6" 4"

EL90500 L90500 90 9.5" 7.5" 5"





















ID/OD
Part #
 OD/OD
Part #		 Bend
Angle		 A+B
Length		 CLR
(Radius)		 Tubing
Size

ID/OD
Part #
 OD/OD
Part #		 Bend
Angle		 A+B
Length		 CLR
(Radius)		 Tubing
Size

L135125 135 5"
 2.5” 1-1/4"

9861204 180 4"
 2" 1-1/4"

9961510 180 6.5" 3" 1-1/2"

9861299 180 3,11"
 2" 1-1/4"

9961524 180 20" 3" 1-1/2"

9861506 180 3" 2.25" 1-1/2"

9961530 180 26" 3" 1-1/2"

9861599 180 6,14" 2.25" 1-1/2"

9961710 180 6" 3.5" 1-3/4"

9861606 180 4" 2.4375" 1-5/8"

9961724 180 19" 3.5" 1-3/4"

9861699 180 6,14" 2.4375" 1-5/8"

9961730 180 25" 3.5" 1-3/4"

9861707 180 3.75" 2.625" 1-3/4"

9962011 180 6" 4" 2"

9861724 180 18" 2.625" 1-3/4"

9962012
 180 12"
 4" 2"

9861799 180 6,14" 2.625" 1-3/4"

9962024 180 19" 4" 2"

9861899 180 6,14" 3" 1-7/8"

9962030 180 28" 4"
 2"

9862008 180 4.5" 3" 2"

9962212 180 6.25" 4.5" 2-1/4"

9862099 180 6,14" 3" 2"

9962213
 180 12"
 4.5" 2-1/4"

9862199 180 6,14" 3" 2-1/8"

9962224 180 19" 4.5" 2-1/4"

9862208 180 4" 3.375" 2-1/4"

9962512 180 5.25" 5" 2-1/2"

9862224 180 18" 3.375" 2-1/4"

9962513
 180 12"
 5" 2-1/2"

9862299 180 6,15" 3.375" 2-1/4"

9962524 180 18" 5" 2-1/2"

9862510 180 6" 3.75" 2-1/2"

9963018 180 10" 6" 3"

9862599 180 6,15" 3.75" 2-1/2"








9862712 180 7.5" 4.125" 2-3/4"








9863012 180 6.5" 4.5" 3"








U350 180
 7.5" 5.25" 3-1/2"








U400 180
 6" 6" 4"



Miscellaneous 1.5D tight radius bend angles:

ID/OD #
 OD/OD #
 Bend Angle
 Length
 CLR
 Size
EL15350
 L15350
 15
 5"
 5.25"
 3.5"
EL15400
 L15400
 15 5.5"
 6"
 4"
EL15500
 L15500
 15 9"
 7.5"
 5"
EL30350
 L30350
 30
 5.5"
 5.25" 3.5"
EL30400
 L30400
 30
 5.5"
 6" 4"
EL30500
 L30500
 30
 9.5"
 7.5" 5"
EL60350
 L60350
 60
 7"
 5.25" 3.5"
EL60400
 L60400
 60
 7.5"
 6" 4"
EL60500
 L60500
 60
 10"
 7.5" 5"
EL75350
 L75350
 75
 6.5"
 5.25" 3.5"
EL75400
 L75400
 75
 9.5"
 6" 4"
EL75500
 L75500
 75
 10"
 7.5" 5"


1 X The Diameter Center Line Radius  (1D bends)

OD/OD
Part #		 Bend
Angle		 Tangent
Length		 CLR
(Radius)		 Tubing
Size
1509017504
 90
 4-1/2"
 1.75"
 1-1/2"
1753017505
 30
 5-3/8"
 1.75"
 1-3/4"
1754517505
 45
 5"
 1.75"
 1-3/4"
1756017505
 60
 4-7/8"
 1.75"
 1-3/4"
1757517505
 75
 4-7/8"
 1.75"
 1-3/4"
1759017505
 90
 4-1/4"
 1.75"
 1-3/4"
17512517505
 125
 5.25"
 1.75"
 1-3/4"
2003020005
 30
 5.25"
 2"
 2"
2004520005
 45
 5.25"
 2"
 2"
2006020005
 60
 4.75"
 2"
 2"
2007520005
 75
 5"
 2"
 2"
2009020006
 90 4.5"
 2"
 2"
20012020007
 120 7.5"
 2"
 2"
20015020007
 150 7.5"
 2"
 2"
2254522504
 45
 4"
 2-1/4"
 2-1/4"
2256022505
 60
 5" 2-1/4"
 2-1/4"
2259022505
 90
 5" 2-1/4" 2-1/4"
22512022505
 120
 5" 2-1/4" 2-1/4"
2504525010
 45
 10"
 2.5"
 2-1/2"
2506025006
 60
 6"
 2.5"
 2-1/2"
2509025006 90 6,10"
 2.5"
 2-1/2"
25012025007
 120 7"
 2.5"
 2-1/2"
3004530006
 45
 6"
 3"
 3"
3009030006
 90 9-1/2"
 3"
 3"
30012030006
 120
 6"
 3"
 3"
30014030010
 140 11.5"
 3"
 3"
LT45500
 45
 10"
 6"
 5"
LT60500
 60
 11"
 6"
 5"
LT90500
 90
 8"
 6"
 5"
LT120500
 120
 10.5"
 6"
 5"
